Size: 4.7" x 2.6" (121mm x 66m)
MOSFET Power Protection, so you can feel safe if you have multiple power supplies, and accidentally plug in the wrong polarity. Compatible up to 18V, however, sounds best at 9V.
Active Volume Control: Supplementing the powerful new Blend feature, is Active Volume Control. This allows players to control the overall output level at any setting.
Blend Control: Our proprietary clean boost circuitry, giving the ability to pan between dry and wet signal. Now for the first time in the history of this pedal’s lineage, you can control how much of the affected wet signal blends with the unaffected dry signal in your mix.
9 Basic Shapes:
• Analog Envelope [forward & reverse]
• Step [tap tempo step filter based on 7 LFO shapes]
• Trigger LFO [tap to trigger one LFO cycle]
• Manual LFO [manually control LFO speed]
• Warp LFO [tap tempo LFO speed with wave shape warp]
• Pixilated Envelope [sample/hold envelope control]
• Envelope Trigger [envelope triggers LFO]
• Envelope–>LFO manual [envelope drives LFO speed. Fixed sensitivity.]
• Envelope–>LFO [envelope drives LFO speed. Variable sensitivity.]
Mode Modifiers: – Numerous modifiers to tweak your shape setting.
Expression Input: – Can be used with any non-envelope functions. Depending on the shape and mode settings, the expression pedal will have a different effect.
All Polyester Film Capacitors -
Input Z (Impedance): 260K (measured, as opposed to theoretical)
Designed and built in the USA
Power Requirement: 9VDC/14mA • NO INTERNAL BATTERY.
Power Adapter Not Included. Requires a 9VDC Center Pin Negative (Fully Regulated power supply, such as the TrueTone 1 SPOT, or any other Power Adapter that will supply 9VDC and AT LEAST 20mA current.)
